TSC Alpha-30L User Manual

51
Cleaning Tools
 Cotton swab
 Lint-free cloth
 Brush with soft non-metallic bristles
 Vacuum cleaner
 75% Ethanol (for disinfecting)
 99% Isopropyl alcohol (for printhead and platen roller cleaning)
 Genuine printhead cleaning pen
 Mild detergent (without chlorine)
Cleaning Process:
Printer Part
Method
Interval
Print Head
I. Always turn off the printer before cleaning the printhead.
II. Allow the printhead to cool for at least one minute.
III. Use a cotton swab and 99% Isopropyl Alcohol or genuine print head cleaning pen to
clean the print head surface.
Clean the print head when
changing a new label roll.
Platen Roller
I. Turn off the printer.
II. Rotate the platen roller and wipe it thoroughly with the lint-free 99% Isopropyl Alcohol.
Clean the platen roller
when changing a new
label roll
Peel Bar
Use the lint-free cloth with 99% Isopropyl Alcohol to wipe it.
As needed
Sensor
Use brush with soft non-metallic bristles or a vacuum cleaner, to remove paper dust.
Clean upper and lower media sensors to ensure reliable Top of Form and Paper Out sensing.
Monthly
Exterior
Clean the exterior surfaces with a clean, lint-free cloth (water-dampened cloth). If necessary,
use a mild detergent or desktop cleaning solution then use the 75% Ethanol to wipe it.
As needed
Interior
Clean the interior of the printer by removing any dirt and lint with a vacuum cleaner, as
described above, or use a brush with soft non-metallic bristles then use the 75% Ethanol to
wipe it.
As needed

TSC Alpha-30L Specifications

General

Color	Yes
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Printable dot numbers	8 dot
Maximum printing width	72 mm
Core diameter	12.7 mm
Media thickness	0.06 - 0.16 mm
Maximum roll diameter	67 mm
Supported paper width	80 mm
Ethernet LAN	No
Optional connectivity	Bluetooth, USB 2.0
Connectivity technology	Wired & Wireless
Internal memory	128 MB
Built-in barcodes	1D, 2D, China post, Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Deutsche Post Identcode, Deutsche Post Leitcode, EAN128, EAN13, EAN14, EAN8, ITF-14, Interleaved 2/5, LOGMARS, PLANET, Standard 2/5, TELEPEN, UPC-A
Page description languages	ESC/POS, TSPL-EZ
Display	LCD
Control type	Buttons
Product color	Black, Grey
Display diagonal	2.3 \
Display resolution	320 x 240 pixels
Battery capacity	3030 mAh
Warranty period	2 year(s)
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	79 mm
Width	117 mm
Height	173 mm
