TSC Alpha-3R User Manual

26
When using the WPA-Personal encryption:
(1) Enter the network name in the SSID field.
(2) Select WPA-Personal in the WLAN Encryption field.
(3) Enter the Wi-Fi network password in the Key field.
(4) Set DHCP to ON. If DHCP is set to OFF, you need to
specify information for the IP Address, Subnet Mask, and
Gateway fields.
(5) Select Set to finish the configuration.
NOTE: The fields marked in yellow indicate that information in the
fields have been changed before selecting Set to finish the
configuration.
NOTE: Users are also allowed to change the name for the printer and
raw port in the Printer Name field and Raw Port field.
When using the WPA-Enterprise encryption:
(1) Enter the network name in the SSID field.
(2) Select WPA-Enterprise in the WLAN Encryption field.
(3) Set DHCP to ON. If DHCP is set to OFF, you need to
specify information for the IP Address, Subnet Mask, and
Gateway fields.
(4) Select EAP type in the EAP Type field.
(5) Upload certificate and key for the CA Certificate, Client
Certificate, and Private Key field respectively.
(6) Select Set to finish the configuration.
NOTE: The fields marked in yellow indicate that information in the
fields have been changed before selecting Set to finish the
configuration.
NOTE: Users are also allowed to change the name for the printer and
raw port in the Printer Name field and Raw Port field.
1
2
1
2
3

TSC Alpha-3R Specifications

General

Flash memory	4 MB
Certification	FCC, CE, CB, CCC, C-Tick, BIS, EAC, IC, NOM, NCC, RoHS, WEEE
Internal memory	8 MB
Built-in barcodes	Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Built-in processor	Yes
Page description languages	CPCL-native, EPL2, ESC/POS, TSPL-EZ, ZPL II
Core diameter	25.4 mm
Media thickness	0.14 mm
Maximum roll diameter	57 mm
Package type	Box
Quantity per pack	1 pc(s)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Storage relative humidity (H-H)	10 - 93 %
Operating relative humidity (H-H)	10 - 90 %
Bluetooth	No
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Optional connectivity	Serial (RS-232)
USB 2.0 ports quantity	1
Connectivity technology	Wired & Wireless
Product color	Black, Grey
Battery voltage	7.4 V
Battery capacity	2500 mAh
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Maximum print height	2286 mm
Maximum printing width	72 mm
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.2 Jaguar, Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks

Weight and Dimensions

Depth	148 mm
Width	116 mm
Height	70 mm
Weight	550 g
