TSC DA220 Series Service Manual

DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
24
4. Disconnect the printhead
harness and the ground cable
connector.
5. Peel off the printhead module
(with fixing cover). Please
DON’T just peel the connector.
6. Press one side of the printhead module then drop down it to remove/replace it.
Let latch to release from top
inner cover.

TSC DA220 Series Specifications

General

Resolution	203 dpi / 300 dpi
Print Speed	Up to 152.4 mm (6”) per second
Print Width	54 mm (2.12”)
Memory	8 MB SDRAM
Processor	32-bit RISC
Interface	USB
Operating Temperature	-40°C to 60°C
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Power Supply	100-240V AC, 50/60 Hz
