TSC DA220 Series

DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
35
3.13 Replacing the Bluetooth Module (Option)
1. Turn the printer upside down
and remove four screws on
the printer lower cover.
2. Disconnect all connectors on
the main board.
3. Disconnect the connector and
remove the four screws on
Bluetooth module to replace
it.
4. Reassemble the parts in the
reverse order.
