TSC DA320 Series Service Manual

DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
18
3.6 Replacing the Media Holder Assembly
1. Please refer to the section 3.3
to remove the lower cover.
2. Remove two screws to take off
the black mylar.
3. Separate the media holders to the remove two screws on one side of media
holder.
4. Replace one side of media holder.

TSC DA320 Series Specifications

General

Brand	TSC
Model	DA320 Series
Category	Barcode Reader
Language	English
