TSC DA320 Series Service Manual

DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
28
3.10 Cutter Module Installation (Option for DA220 series)
1. Open the printer top cover
by pressing up the top cover
open tabs located on each
side of the printer.
2. Remove the lower front
panel.
3. Remove four screws on the
printer lower cover.
4. Thread the cutter module
8-pin harness and ground
cable through the front slot
of lower inner cover.
