DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
23
3.8 Replacing the Printhead Module
1. Press tabs of gap sensor cover to release from the printer. Please DON’T let cover
to press the printhead module.
2. Drop down the cover as picture (O) shown. The cover CANNOT press the
printhead module.
3. Disconnect the gap sensor
connector to remove the cover.
O
X
