TSC DA320 Series

DA210/ DA310/ DA220/ DA320
Bar Code Printer Service Manual
22
7. Please make sure the lower cover has been installed into the media holder base.
8. Use needle-nose pliers to install the spiral spring back.
9. Screw two screws to replace the upper cover of sprial spring assembly.
Reassemble the parts in the reverse procedure.
