TSC TA200 Series User Manual

9
4. Push the print head release button
to open the print head mechanism.
5. Feed the paper, printing side face
up, through the media bar, media
sensor and place the label leading
edge onto the platen roller. Move
the media guides to fit the label
width.
Note: The media sensor position is moveable. Please make sure the gap or black
mark is at the location where media gap/black mark will pass through for
sensing.
Gap sensor
Black mark sensor
Media guide
Gap sensor
Black mark
sensor
Platen roller
