TSC TDP-225 Series User Manual

5
2.2.3 Rear View
1. Fan-fold paper entrance chute
2. Power switch
3. Power jack socket
4. USB interface
5. RS-232C interface
Note: The interface picture here is for reference only. Please refer to the product specification for the interfaces availability.
4
5
2
3
1
4
5
2
3
1
1. Power switch
2. Power jack socket
3. USB interface
4. USB host (Factory option for TDP-225W/324W model)
5. Ethernet interface (Option for TDP-225/324 model)
TDP-225/324 model
TDP-225W/324W model
