9
3.3 Peel-Off Installation Assembly (Option)
1. Open the top cover.
2. Unscrew the 6 screws in the lower inner cover.
3. Upside down the printer.
4. Unscrew the 2 screws at the lower inner cover
5. Remove the screw at memory card cover.
Remove the
screw
Remove the
screw
Screw
Screws
Screws
