5
2.3 Printer Parts
2.3.1 Front View
2.3.2 Rear View
Note: The interface picture here is for reference only. Please refer to the product specification for
the interfaces availability.
1
1. USB Interface
2. Centronics Interface
3. RS-232C DB-9 Interface
4. Power Jack
5. Power Switch
6. Rear Label Guide
Top Cover Open Lever
LED Indicator
Feed Button
Top Cover
Clear Window
Backing Paper Opening
Label Opening
Front Panel
