TSC TE210 Series User Manual

4
Peeler module
○
Regular full cut cutter (Guillotine cutter)
Paper thickness: 0.06~0.19 mm
○
Regular full/partial cutter (Guillotine cutter)
Paper thickness: 0.06~0.19 mm
○
1.3 General Specifications
General
Specifications
TE200/TE300
TE210/TE310
Physical dimensions
204 mm (W) x 164 mm (H) x 280 mm (L)
Weight
2.4kg
2.5kg
Electrical
External universal switching power supply
Input: AC 100-240V, 2A, 50-60 Hz
Output: DC 24V, 2.5A, 60W, LPS
Environmental
condition
Operation: 5 ~ 40˚C (41 ~ 104˚F), 25~85% non-condensing
Storage: -40 ~ 60 ˚C (-40 ~ 140˚F), 10~90% non-condensing
1.4 Print Specifications
Print
Specifications
TE200
(203 dpi model)
TE300
(300 dpi model)
TE210
(203 dpi model)
TE310
(300 dpi model)
Print head
resolution
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Thermal transfer and direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 11.8 dots)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 11.8 dots)
Print speed
(inches per
second)
Up to 6 ips
Up to 5 ips
Up to 6 ips
Up to 5 ips
Print speed for
peel mode
N/A
Up to 3 ips
Max. print width
108 mm (4.25”)
105.7 mm (4.16”)
108 mm (4.25”)
105.7 mm (4.16”)
Max. print length
2,794 mm (110”)
1,016 mm (40”)
25,400 mm (1000")
11,430 mm (450")

TSC TE210 Series Specifications

General

Resolution	203 DPI
Print Speed	6 IPS
Print Method	Thermal transfer / Direct thermal
Processor	32-bit RISC CPU
Interface	USB 2.0, RS-232, Ethernet
Scan Rate	N/A (Barcode printer, not a barcode reader)
Barcode Resolution	N/A (Barcode printer, not a barcode reader)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, POSTNET
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	25 ~ 85% non-condensing (Operating)
Power Consumption	100-240V AC, 50/60Hz
