TSC TE210 Series

8
2.2.2 Interior View
1. Printer top cover
8. Media supply spindle
2. Ribbon supply spindle
9. Platen roller
3. Ribbon supply hub
10. Black mark sensor
4. Ribbon rewind hub
11. Gap sensor
5. Ribbon rewind spindle
12. Media guide
6. Print head release button
13. Media guide adjustment knob
7. Fixing tabs
14. Print head
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER
BODY PARTS AWAY
OPEN
7
6
1
4
5
8
13
12
14
9
11
10
2
3
