TSC TE210 Series User Manual

15
4. Push the print head release button
to open the print head mechanism.
Note: The black mark sensor position is moveable and the gap sensor is fixed.
Please make sure the gap or black mark is at the location where media gap/black
mark will pass through for sensing.
5. Feed the paper, printing side face
up, through the media sensor and
place the label leading edge onto
the platen roller. Move the media
guides to fit the label width.
6. Close the print head mechanism
with both hands and make sure the
latches are engaged securely.
Platen roller
Black mark
sensor
Gap sensor

TSC TE210 Series Specifications

General

Resolution	203 DPI
Print Speed	6 IPS
Print Method	Thermal transfer / Direct thermal
Processor	32-bit RISC CPU
Interface	USB 2.0, RS-232, Ethernet
Scan Rate	N/A (Barcode printer, not a barcode reader)
Barcode Resolution	N/A (Barcode printer, not a barcode reader)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, POSTNET
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	25 ~ 85% non-condensing (Operating)
Power Consumption	100-240V AC, 50/60Hz
