TSC TE210 Series User Manual

20
5. Close the print head mechanism as
indicated.
6. Close the printer cover. Use the
“Diagnostic Tool” to set the printer
for cutter mode by selecting
“CUTTER” option for Post-Print
Action setting then click “Set”
button to enable the cutter mode.
Press the FEED button to test.
Note:
Please calibrate the gap/black mark sensor when changing media.

TSC TE210 Series Specifications

General

Resolution	203 DPI
Print Speed	6 IPS
Print Method	Thermal transfer / Direct thermal
Processor	32-bit RISC CPU
Interface	USB 2.0, RS-232, Ethernet
Scan Rate	N/A (Barcode printer, not a barcode reader)
Barcode Resolution	N/A (Barcode printer, not a barcode reader)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, POSTNET
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40 ~ 60°C (-40 ~ 140°F)
Humidity	25 ~ 85% non-condensing (Operating)
Power Consumption	100-240V AC, 50/60Hz
