TSC TH240 Series

10
Model
(HC: Healthcare)
TH240
TH340
TH240T (HC)
TH340T (HC)
Supported Barcode
Formats
 1D Barcodes
Code 39, Code 93, Code128UCC, Code128 subsets A.B.C, Codabar, Interleaved 2 of 5, EAN 8, EAN 13,
EAN 128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China post, ITF14,
EAN14, Code 11, TELEPEN, TELEPENN, PLANET, Code 49, Deutsche Post Identcode, Deutsche Post
Leitcode, LOGMARS
 2D Barcodes
TLC39, CODABLOCK F mode, PDF-417, Maxicode, DataMatrix, QR code, Aztec, Micro PDF 417, GS1
DataBar (RSS barcode)
Font & Barcode Orientation
0 / 90 / 180 / 270 degree
Printer Language
TSPL-EZD (compatible to EPL, ZPL, ZPL II, and DPL)
Media Type
Continuous, Die-cut, Black mark, Fanfold, Notch (outside wound)
Media Width
15 – 120 mm (0.59” – 4.72”)
Peel mode and Cutter mode: 15 – 112 mm (0.59” – 4.40”), including the liner
Media Thickness
0.06 – 0.19 mm (2.36 – 7.48 mil)
Care label media: 0.06 – 0.10 mm (2.36” – 3.937 mil)
Media Core Diameter
25.4 – 38.1 mm (1” – 1.5”)
Label Length
▪ 5 – 25,400 mm (0.2” –
1,000”)
▪ Peel mode: 25.4 –
152.4 mm (1” – 6”)
▪ Cutter mode: 25.4 –
25,400 mm (1” –
1000”)
▪ 5 – 11,430 mm (0.2” –
450”)
▪ Peel mode: 25.4 –
152.4 mm (1” – 6”)
▪ Cutter mode: 25.4 –
11,430 mm (1” – 450”)
▪ 5 – 25,400 mm (0.2” –
1,000”)
▪ Peel mode: 25.4 –
152.4 mm (1” – 6”)
▪ Cutter mode: 25.4 –
25,400 mm (1” –
1000”)
▪ 5 – 11,430 mm (0.2” –
450”)
▪ Peel mode: 25.4 –
152.4 mm (1” – 6”)
▪ Cutter mode: 25.4 –
11,430 mm (1” – 450”)
Environment Condition
▪ Operation: 0 to 40°C (32 to 104°F), 25 to 85% (non-condensing)
▪ Storage: -40 to 60°C (-40 to 140°F), 10 to 90% (non-condensing)
▪ Care label print: 20°C (68°F), 65% (non-condensing)
