26
4.3 Loading the Ribbon (for TH240 Series only)
1. Pull the release latches to open the printer’s top cover.
2. Open the ribbon access cover.
3. Orient the core adapter as indicated and then insert the core
adapter into the supplied rewind paper core.
4. Push the right side of the paper core onto the right spring-loaded
spindle and then align the left side of the paper core with the left
spindle’s hub ensuring that the square rib on the core adapter fits
into the left spindle.
R
L
