7.6 Diagnostic
The illustration and table below describe the functions in the Diagnostic menu.
Item
Description
Print Config.
Prints the printer’s configurations. You can use this function to check if there is a defective dot on the
print heater.
Dump Mode
In this mode, all received characters will be printed in a two-column format. The left column displays the
data which is sent from your computer while the right column shows the same data in the hexadecimal
format. This function helps engineers troubleshoot a specific problem.
Diagnostic
Print Config.
Dump Mode
Print Head
Display
Sensor
