TSC TTP-244 User Manual

printer is error then it's ribbon sensor
problem. Please check the following
items.
(1) Is outside wound ribbon is used
with this printer?
(2) Is ribbon threaded correctly in
the mechanism?
(3) Is paper core installed on the
ribbon take up spindle?
2. Calibrate the sensitivity of gap
sensor.
Continuous feeding when printing
labels
1. Check the driver or command script
setting if sensor type is set properly.
2. Calibrate the gap sensor again if die
cut media is used for printing.
24

TSC TTP-244 Specifications

General

Print Resolution	203 DPI
Print Method	Thermal Transfer / Direct Thermal
Max. Print Speed	4 ips (inches per second)
Max. Print Width	4.09 inches (104 mm)
Processor	32-bit RISC
Interface	USB
Maximum Print Width	4.09 inches (104 mm)
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, POSTNET
Power Supply	100-240V AC, 50/60Hz
