13
32
Error / Fault
N/A
Out
33-35
Ground
N/A
GND
36
No Defined
N/A
N/A
Ethernet
PIN
CONFIGURATION
1
Tx+
2
Tx-
3
Rx+
4
N/C
5
N/C
6
Rx-
7
N/C
8
N/C
GPIO
