12 Displayed Items
Run
Displayed Items
For the QUESTemp 48N Heat Stress Monitor, the number in the upper right corner indicates
the saved session or the saved event log.
 “1”indicates the sensor bar placed on (or attached to) the top of the instrument. Sensors
2 and 3 are labeled on the side of the unit as “Sensor 2”, and “Sensor 3”.
 An “*” asterisk in the lower right corner indicates that the unit is in the run mode and is
logging data or saves an event.
The following measurements can be accessed on the display:
Screen 1: WET (Wet bulb)
DRY (Dry bulb)
WET 80.5º F  01
DRY 92.2º F 
Figure 1-15: Wet and Dry screen
Screen 2: GLOBE and RH
GLOBE 40.4°C  03
RH 52.5% 
Figure 1-16: Globe and RH screen
Screen 3: WBGT
WBGT 30.7°C  3

Figure 1-17: WBGT screen
Screen 4: Time (24 hour format)
Date (day, month, year)
TIME 11:04:13  04
DATE 14-MAY-18 
Figure 1-18: Time and Date screen
