13 Displayed Items
Stay Time/Index
Screen 5: BAT (Battery voltage)
MEM (Logging memory
available in days)
BAT 09:04:13 05
DATE 10.4 dy
Figure 1-19: Battery & memory screen
Screen 6: Index
(Navy PHEL stay times)
PHEL_5 3:10 05
PHEL_6 8:03
Figure 1-20: Navy PHEL stay times
NOTE: A series of dashes appear in the display if one of the following occur:
The temperature is outside of its allowable range
A temperature sensor has failed
Stay times temperatures are outside of the their defined range
Stay Time/Index
The screen(s) displaying stay time data appear different for each of the possible indices.
If ACGIH is selected, the recommended working minutes per hour are shown for each of the
workload categories Light (L), Moderate (M), Heavy (H), and Very Heavy (VH).
Figure 1-21: Index for ACGIH
If the Navy PHELs are selected, the recommended working hours are shown based on a
maximum of eight hours. Three screens are used to display the PHELs two at time.
NOTE: “8:01” following one of the PHELs indicates greater than eight hours.
PHELs stay time is greater than 8 hours.
Figure 1-22: Navy PHELs screen
