5 Getting Started
Turning on, Logging/Capture an Event, and Turning Off
4. The main menu (navigational screen) will appear after the start-up screens. Press I/O
Enter key. (This will open to the measurement screens.)
Indicates the selected menu option. Either press
up/down arrows to select a new menu or press I/O
Enter key to select.
Figure 1-6: Main menu of the QT48N
5. Press Run/Stop key to either Data Log or log/record an Event and an asterisk will appear
in far right corner.
NOTE: Data logging or an Event is selected via the Setup menu.
Numeric counter
o Event logging/recording: As you record events, the numeric counter will
increase by one displaying the number of saved events.
o Data logging mode: This will display the number of saved data logged
sessions instead of Events. (The process is identical to event mode.)
Numeric counter
Event records or Data logging sessions
displayed
Run indicator.
Will appear when you are in “Run mode”.
For an event, it will appear for about 1-2
seconds as an event is recorded in the
instrument’s history.
WET 53.9º F 01
DRY 113.5º F
Figure 1-7: Measurement screen (example)
6. To stop data logging, press and hold Run/Stop key.
NOTE: Skip this step for an Event log. An event log will capture the measurements
with the initial run/stop key press.)
7. To view different measurements, press the Up or Down Arrow key to toggle through the
views.
8. To return to the main menu, press and hold the I/O Enter key (3, 2, 1 countdown will
appear) and the main menu will display.
To select an option on the main menu, press the Up or Down Arrow until an arrow
appears directly in front of the appropriate menu selection and then press I/O enter
key.
