TuffStuff AXT-2.5 - Step 9 a: Abdominal Cable Assembly; Step 9 Assembly List

1
B9
B8
B1 B7
B6
B3
B5
B4
B2
Step 9a Abdominal Cable Assembly
Step 9 Assembly List
Item # Description Qty.
1 ABDOMINAL CABLE 1
116 NYLON BALL 1 3/4 X 5/16 1
122 NYLON INSERT LOCK NUT 5/16-18 2 142 SHOULDER BOLT 3/8 X 3/4 2 144 SNAP LINK Z/P 8MM X 80MM 1 146 SOC SET SCREW 3/8-16 X 3/4 1 154 STRAP BRACKET 20 #SF20 1
12 AXT-2.5 AXT- Cable Motion Plus Home Gym
142
116 146
154
122
122
142
1
