TuffStuff AXT-2.5 - Step 10 a: Leg Extension Cable Assembly; Step 10 Assembly List

37
22
C1
C2
C3
C4
Step 10a Leg Extension Cable Assembly
142
122
22
116
146
152
79
150
154
Step 10 Assembly List
Item # Description Qty.
22 LEG EXTENSION CABLE 1
79 FINISHED HEX NUT 1/2-13 1
116 NYLON BALL 1 3/4 X 5/16 1
122 NYLON INSERT LOCK NUT 5/16-18 1 142 SHOULDER BOLT 3/8 X 3/4 1 144 SNAP LINK Z/P 8MM X 80MM 1 146 SOC SET SCREW 3/8-16 X 3/4 1 150 SPLIT HEX TAP BOLT 1/2-13 X 3 1/2 1 152 SPLIT LOCK WASHER Z/P 1/2” 1 154 STRAP BRACKET 20 #SF20 1
14 AXT-2.5 AXT- Cable Motion Plus Home Gym
