TuffStuff AXT-2.5 - Step 11 a: Pec Fly Cable Assembly; Step 11 Assembly List

24
117
117
D1
D2
D6
D3
D5
D7
D4
Step 11a Pec Fly Cable Assembly
142
146 116
116 146
154
122
122
154
142
24
Step 11 Assembly List
Item # Description Qty.
24 PEC FLY CABLE 1
116 NYLON BALL 1 3/4 X 5/16 2 117 NYLON D HANDLE 2
122 NYLON INSERT LOCK NUT 5/16-18 2 142 SHOULDER BOLT 3/8 X 3/4 2 144 SNAP LINK Z/P 8MM X 80MM 2 146 SOC SET SCREW 3/8-16 X 3/4 2 154 STRAP BRACKET 20 #SF20 2
16 AXT-2.5 AXT- Cable Motion Plus Home Gym
