TuffStuff AXT-2.5 - Step 12 a: Tension Cable Assembly; Step 12 Assembly List

Step 12a Tension Cable Assembly
Step 12 Assembly List
Item # Description Qty.
39 TENSION CABLE 1
88 FLAT WASHER SAE 3/8” 2 98 HEX HEAD CAP SCREW 3/8-16 X 1 3/4 1
120 NYLON INSERT JAM LOCK NUT 3/8-16 1 122 NYLON INSERT LOCK NUT 5/16-18 2 142 SHOULDER BOLT 3/8 X 3/4 2 154 STRAP BRACKET 20 #SF20 1
18 AXT-2.5 AXT- Cable Motion Plus Home Gym
39
E1
E2
154 142
122
39
