REV1
ITEM DESCRIPTION REV PART NO. QTY ITEM DESCRIPTION PART NO. QTY
1 ABDOMINAL CABLE 1 UP5875 1
47 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16 BNH1650 19
2 ADJUSTABLE BACK PAD BRACKET 0 UP3703 1
48 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS BNH1982 1
3 ADJUSTABLE DOUBLE PULLEY BRACKET 0 UP3704 1
49 ABDOMINAL STRAP BNH0821 1
4 ADJUSTABLE LEG HOLDER 0 UP3735 1
50 ACCESSORY HOLDER BNH1764 1
5 ADJUSTABLE PRESS BAR CABLE 0 UP5253 1
51 ADJUSTABLE RELEASE LEVER COVER BNH1940 1
6 ADJUSTABLE RELEASE LEG HOLDER 0 UP3739 1
52 ALUMINUM WASHER .390 ID X 1.500 OD BNH1541 6
7 ADJUSTABLE SEAT FRAME 0 UP3783 1
53 ANKLE STRAP BNH1435 1
8 ADJUSTABLE SEAT HANDLE 0 UP3732 1
54 BALL BEARING #W 516 BNH0628 4
9 BACK PAD 0 UP3705 1
55 BEARING 6203 W/BUSHING BNH0843 2
10 BASE FRAME 0 UP5876 1
56 BEARING SPACER 2 7/8 BNH1941 1
11 BOTTOM GUIDE ROD RETAINER 0 UP3811 1
57 BLACK NYLON PULLEY 3/8 X 1 1/2 X 4 1/2 BNH1694 4
12 CABLE RETAINER BRACKET (3 1/2 PULLEY) 0 UP0998 1
58 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 BNH0553 9
13 CHROME GUIDE ROD 3/4 X 73 5/8 0 UP3731 2
59 BLACK NYLON PULLEY 3/8 X 1 X 4 1/2 BNH0506 18
14 DOUBLE PULLEY BRACKET 3 1/2 PULLEY 0 UP5877 1
60 BLACK RUBBER GRIP 1/2 X 4 7/8 BNH1818 3
15 FLOATING PULLEY BRACKET 0 UP3733 2
61 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 2
16 FOAM FOOT ROLL 1 X 4 X 7 W/VINYL 0 UP3785 6
62 BRONZE BUSHING 1/2 X 5/8 X 1/2 X 7/8 X 1/8 BNH0528 6
17 FOAM ROLL TUBE 1 X 25 1/2 0 UP5004 1
63 BRONZE BUSHING 3/8 X 1/2 X 5/16 BNH0737 2
18 FRONT UPRIGHT 0 UP5878 1
64 BRONZE FLANGED BUSHING 3/8 X 1/2 X 3/16 BNH2146 2
19 LAT BAR HOLDER 0 UP3744 1
65 BUTTON HEAD SOC CAP SCREW B/O 3/8-16 X 1 BNH0115 8
20 LAT CABLE 0 UP5879 1
66 CHROME WASHER 3/8 X 1 1/2 BNH1015 4
21 LEG EXTENSION ARM 0 UP3734 1
67 COIL CHAIN Z/P 3/16 X 21 BNH1262 1
22 LEG EXTENSION CABLE 0 UP5880 1
68 CUP HOLDER BNH1763 1
23 LONG ADJUSTABLE STOPPER 0 UP0331 1
69 DECAL-ADJUST CABLE HERE BNH1751 3
24 PEC FLY CABLE 0 UP5881 1
70 DECAL-ADJUSTMENT BACK PAD BNH1749 1
25 PEC FLY SWIVEL PULLEY BRACKET LT SIDE 0 UP5882 1
71 DECAL-ADJUSTMENT PRESS BAR BNH1748 1
26 PEC FLY SWIVEL PULLEY BRACKET RT SIDE 0 UP5883 1
72 DECAL-CAUTION FOR CHINNING (1 1/4 X 2 3/4) BNH1742 1
27 PIVOT AXLE 1/2 X 3 0 UP3741 1
73 DECAL-CAUTION WEIGHT TRAINING BNH1743 1
28 PRESS BAR 0 UP5254 1
74 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2 BNH1745 2
29 PRESS BAR ADJ HANDLE 0 UP5252 1
75 DECAL-FOR BEST PERFORMANCE BNH1750 1
30 PRESS BAR HANDLES 0 UP3618 2
76 DECAL-WARNING KEEP HANDS AND FINGERS... BNH1744 1
31 PRESS BAR HOUSING 0 UP3718 1
77 DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs) BNH1542 1
32 PRESS BAR PIVOT AXLE 1 X 5 5/8 0 UP3796 1
78 EDGE PROTECTOR CHROME 18 GA X 78 BNH1836 2
33 REAR UPRIGHT 1 UP3621 1
79 FINISHED HEX NUT B/O 1/2-13 BNH0201 4
34 SEAT PAD 0 UP3724 1
80 FLANGED SPACER 0.406 X 0.63 X 0.63 (0.551) BNH1781 2
35 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 0 UP3035 1
81 FLANGED SPACER 0.406 X 0.63 X 0.689 (0.610) BNH2151 2
36 STOPPER HOUSING BLOCK 0 UP3745 1
82 FLANGED SPACER 0.406 X 0.63 X 0.827 (0.748) BNH1782 2
37 SWIVEL CABLE END 0 UP2032 1
83 FLANGED SPACER 0.406 X 0.63 X 1.602 (1.595) BNH1778 2
38 SWIVEL FOOT ROLL HOLDER 0 UP4397 1
84 FLANGED SPACER 0.406 X 0.63 X 1.693 (1.614) BNH1777 2
39 TENSION CABLE 1 UP5884 1
85 FLAT HEAD SOCKET CAP SCREW B/O #12-28 X 3/4 BNH1787 5
40 TOP FRAME 0 UP3738 1
86 FLAT PHILLIPS SCREW ZINC # 2 X 1/2 BNH1480 4
41 TOP FRAME REINFORCEMENT PLATE LT SIDE 0 UP5885 1
87 FLAT WASHER SAE B/O 1/2" BNH0238 5
42 TOP FRAME REINFORCEMENT PLATE RT SIDE 0 UP5886 1
88 FLAT WASHER SAE B/O 3/8" BNH0239 107
43 TOP GUIDE ROD RETAINER 0 UP3729 1
89 FLAT WASHER USS B/O 1/4" BNH0233 4
44 WEIGHT SHROUD FRONT 0 UP5887 1
90 GAS SHOCK BNH0747 1
45 WEIGHT SHROUD REAR 0 UP5888 1
91 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 3 3/4 BNH0297 1
46 WING ARMS 0 UP5889 1
92 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 5 BNH0268 1
AXT-2.5
Parts List
COLOR CHART
BOLD FONT = SUB-ASSEMBLY PARTS
BLACK= HARDWARE
30 AXT-2.5 AXT- Cable Motion Plus Home Gym
