31AXT-2.5 AXT- Cable Motion Plus Home Gym
REV1
ITEM DESCRIPTION REV PART NO. QTY ITEM DESCRIPTION PART NO. QTY
AXT-2.5
Parts List
COLOR CHART
BOLD FONT = SUB-ASSEMBLY PARTS
BLACK= HARDWARE
93 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 6 1/2 BNH1370 1 128 PLASTIC INSERT CAP 2" RD 10-14 GA BNH0004 2
94 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4 BNH0890 4 129 PLASTIC INSERT CAP ELLIPTICAL 1 1/2 X 3 BNH1795 1
95 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 BNH0275 5 130 PLASTIC INSERT ELLIPTICAL GUIDE (2X4) BNH1760 2
96 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/2 BNH0303 5 131 PLASTIC STOPPER BNH1765 1
97 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4 BNH0273 1 132 PULL PIN 1/2 X 5 5/8 (YELLOW KNOB) BNH0701 1
98 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 17 133 PULL PIN STIFF SPRING 17/32 X 1 1/2 K-105SS BNH0519 2
99 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/2 BNH0276 2 134 RETAINING SNAP RING EXT. PLAIN .925 X 1 X .042 BNH0419 2
100 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/4 BNH0277 3 135 RUBBER BUMPER W/WASHER 3/8 X 1 1/2 BNH0514 1
101 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 3/4 BNH0278 1 136 RUBBER DONUT 3/4 X 2 1/2 BNH0068 2
102 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 BNH0282 2 137 RUBBER FOOT FOR 6 X 4 1/4 PLATE BNH1647 3
103 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 BNH0312 4 138 RUBBER GRIP 1.1875 ID X .125 X 4 1/4 BNH0936 2
104 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4 BNH0283 2 139 RUBBER GRIP 1.1875 ID X .125 X 4 3/4 BNH1244 6
105 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/2 BNH0284 4 140 RUBBER GRIP 1/2 X 3 1/2 BNH1221 1
106 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 5 BNH0320 15 141 RUBBER GROMMET 3/4" ID BNH0401 2
107 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 5 1/4 BNH0690 4 142 SHOULDER BOLT 3/8 X 3/4 BNH0718 9
108 HEX HEAD CAP SCREW GR-5 B/O 5/16-18 X 3/4 BNH1772 2 143 SINGLE STRAND CONNECTING LINK #40 BNH0066 1
110 HEX KEY 7/32" BNH0575 2 144 SNAP LINK Z/P 8MM X 80MM BNH0065 6
111 HEX KEY ARM 1/8" BNH0767 1 145 SOC SET SCREW 1/4-20 X 1/4 BNH0790 1
112 HEX KEY ARM 3/16" BNH0371 1 146 SOC SET SCREW 3/8-16 X 3/4 BNH0476 5
113 LAT BAR 1 1/4 ALUMINUM BNH1770 1 147 SOCKET HEAD CAP SCREW B/O 1/4-28 X 3/4 BNH2161 4
114 LOW ROW BAR 1 1/4 ALUMINUM BNH1771 1 148 SPACER 0.406 X 0.63 X 1.890 BNH1780 1
115 METAL HINGE BNH0046 2 149 SPLIT COLLAR 1" BNH0755 2
116 NYLON BALL 1 3/4 X 5/16 BNH0022 5 150 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 BNH1131 2
117 NYLON D HANDLE BNH1215 2 151 SPLIT LOCK WASHER B/O 3/8" BNH0658 17
118 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 BNH0393 2 152 SPLIT LOCK WASHER Z/P 1/2" BNH0572 3
119 NYLON INSERT JAM LOCK NUT B/O 1/2-13 BNH0366 3 153 STEEL BUMPER WASHER Z/P 1/2" BNH1800 2
120 NYLON INSERT JAM LOCK NUT B/O 3/8-16 BNH0365 28 154 STRAP BRACKET 20 #SF20 STAINLESS STEEL BNH0562 6
121 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 26 155 TUFFSTUFF LOGO ALUMINUM SMALL BNH1323 2
122 NYLON INSERT LOCK NUT B/O 5/16-18 BNH0215 9 156 URETHANE BUMPER 1 3/4 BNH0229 3
123 NYLON STEM BUTTON .720" X .187" BNH0533 2 157 U-STYLE TAPPED HOLE NUT 1/4-20 BNH0708 4
124 PLASTIC END CAP BLACK-BUMPER (1/2 BOLT) BNH1801 2 158 WEIGHT STACK LID BNH1693 1
125 PLASTIC FOOT ROLL HOLDER 1.03 X 2.35 BNH1807 12 159 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 5 1/2 BNH0286 1
126 PLASTIC INSERT CAP 1 1/4" RD 11 GA BNH0573 10 160 DECAL-EXERCISE CHART AXT-2.5 BNH2160 1
127 PLASTIC INSERT CAP 2 X 3 _ 11-14 GA BNH0052 1 161 SOC SET SCREW 1/4-20 X 3/8 BNH0772 2
