TuffStuff AXT-2.5 - Step 14: Seat and Back Pad Assembly; Step 14 Assembly List

96
88
88
7
34
115
96 88
9
135
96
2
115 88 96
21AXT-2.5 AXT- Cable Motion Plus Home Gym
Step 14
Step 14 Assembly List
Item # Description Qty.
9 BACK PAD 1
34 SEAT PAD 1
88 FLAT WASHER SAE 3/8” 4
96 HEX HEAD CAP SCREW 3/8-16 X 1 1/2 5
115 METAL HINGE 2
135 RUBBER BUMPER W/WASHER 3/8 X 1 1/2 1
