TuffStuff CLH-300 - Step 2: Carriage and Shaft Assembly

www.tu stu tness.comCLH-300 Horizontal Plate Load Leg Press/Hack Squat
ŘŘ
Řŝ
ŘŚ
ş
ş
Șś
ş
ş
ş
ş
NOTE:
1. SLIDE LINEAR SHAFTS INTO CARRIAGE.
REAR VIEW
100%
Fully Tighten
Fully Tighten
Wrench tighten all hardware in this step.
Step 2
13
Step 2 Assembly List
Item # Description Qty.
*5 CARRIAGE 1
9 LINEAR SHAFT 2 RD. X 48 1/4 2
22 FLAT WASHER SAE Z/P 3/8” 2
24 SPLIT LOCK WASHER Z/P 3/8” 2
27 HEX HEAD CAP SCREW GR-5 Z/P 3/8-16 X 1 2
