TuffStuff CLH-300 - Rail Wheel Replacement Procedures (Cont.); Steps 3 & 4: Wheel Replacement and Reassembly

www.tu stu tness.comCLH-300 Horizontal Plate Load Leg Press/Hack Squat
21
Rail Wheel Replacement Step 3
Rail Wheel Replacement Step 4
INSTALLATION IS THE REVERSE OF REMOVAL. (DO NOT INSTALL THE SEAT PAD UNTIL
COMPLETING RAIL WHEEL ADJUSTMENT ON NEXT PAGE)
Note:
1. INVERT THE CARRIAGE ON THE FLOOR TO PERFORM
THIS STEP.
2. REPLACE ANY DAMAGED RAIL WHEELS.
