www.tu stu tness.comCLH-300 Horizontal Plate Load Leg Press/Hack Squat
23
Rail Wheel Adjustment Step 2
STEP 9
WHILE HOLDING SCREW
FROM STEP 7 WITH AN
ALLEN WRENCH, GENTLY
FULLY TIGHTEN NUT
USING A 9/16” SOCKET.
STEP 11
TIGHTEN SCREW ENOUGH
TO ALLOW THE CARRIAGE
TO ROLL SMOOTHLY.
STEP 7
GENTLY SCREW BACK IN UNTIL YOU FEEL THE WHEELS HAVE COME INTO
CONTACT WITH THE LINEAR SHAFTS. ROLL THE CARRIAGE BACK AND FORTH
TO TEST FOR SMOOTHNESS. IF IT ROLLS SMOOTHLY YOU MAY PROCEED TO
NEXT STEP. IF NOT, MAKE NECESSARY ADJUSTMENTS.
STEP 10
TIGHTEN SCREW ENOUGH
TO ALLOW THE CARRIAGE
TO ROLL SMOOTHLY
STEP 8
WHILE HOLDING SCREW
FROM STEP 7 WITH AN
ALLEN WRENCH, GENTLY
FULLY TIGHTEN NUT
USING A 9/16” SOCKET.
To Next Page
