15
OVEN MODES
EC=82F 208V
RUN: 65432 HR
IDLE: 12345 HR
INFO
SERIAL_NUMBER
SOFTWARE VERSION
Figure 24: Info Screen
DEGS F
BELT L-R
EDIT/RIGID/FLEX
ENGLISH
SETUP MENU
VOL 3
INFO
Figure 21: Setup Mode
Changing the Display Temperature
The oven can display the temperature in either
Celsius or Fahrenheit units. To change the display
temperature, press L1 in (Figure 21).
Changing the Belt Direction
The oven’s belt(s) can travel from left to right or
right to left. To change the belt direction, press
L2 in (Figure 21).
Edit Options Screen
The edit options screen (Figure 23) allows the
user to switch between full edit, rigid, and flex
options for profile name, belt speed, temperature,
and % air. For more information on the different
edit options, see Editing a Cooking Profile on
page 12.
To access the edit options screen,
1. Press L3 (Figure 21) to access the password
screen (Figure 22).
2. Input the password 6 6 3 3 by pressing the
soft keys adjacent to the numbers.
To change the edit option (Figure 23),
- Press L1 to select full edit or rigid for the
profile name.
- Press L3 to select full edit, rigid, or flex for
the belt speed.
- Press R1 to select full edit, rigid, or flex for
the profile cook temperature setting.
- Press R3 to select full edit, rigid, or flex for
the % air setting.
Changing the Speaker Volume
Press R2 (Figure 21) to change the volume of the
speaker. The volume can be set to either 0, 1, 2,
or 3 (where 0 is mute and 3 is the loudest
setting).
F1: 0
F2: 0
F3: 0
F4: 0
F5: 0
F6: 0
F7: 0
F8: 0
F9: 0
F10: 0
FAULT COUNTS
Figure 20: Fault Counts Screen
1
2
3
4
5
<6633>
6
ENTER PASSWORD
Figure 22: Password Screen
NAME: FULL
BELT: RIGID
EDIT MODES
SELECT
TEMP: FLEX
AIR: FLEX
Figure 23: Edit Option Screen
L1
L2
L3
R1
R2
R3
L1
L2
L3
R1
R2
R3
L1
L2
L3
R1
R2
R3
L1
L2
L3
R1
R2
R3
L1
L2
L3
R1
R2
R3
To Next Page
