TurboChef 2020 Service Manual

SPECIFICATIONS AND INSTALLATION
1
Dimensions
Exterior
Height 13.0” (330 mm)
--with legs 17.0” (432 mm)
Width 48.3” (1227 mm)
--with extensions 60.1” (1527 mm)
D
epth 35.7” (907 mm)
Conveyor
Length 48.3” (1227 mm)
Width (Single) 20.0” (508 mm)
Width (50/50) 9.5” / 9.5” (241 mm / 241 mm)
Width (70/30) 15” / 4” (381 mm / 102 mm)
Electrical Specifications
North America
3 Phase
208/240 VAC
50/60 Hz
40 amp curr
ent draw
4-wir
e supply
NEMA 15-50P plug (4-pin IEC60309 av
ailable b
y
special or
der)
50-amp max cir
cuit br
eaker pr
otection
E
urope/Asia (220-240 VAC)
3 Phase
220-240
VAC
50/60 Hz
40 amp current draw
4-wir
e supply
IEC60309 4-pin plug
64-amp max cir
cuit breaker protection
E
urope/Asia (380-415 VAC)
3 Phase
380-415 VAC
50/60 Hz
20 amp current draw
5-wir
e supply
IEC60309 5-pin plug
32-amp max circuit breaker protection
35.7” (907 mm)
8.5”
(216 mm)
48.3” (1227 mm)
13.0”
(330 mm)
17.0”
(432 mm)
4.0” (102 mm)
60.1” (1527 mm) with extensions
43.0”
(1092 mm)
13.0”
(330 mm)
13.0”
(330 mm)
13.0”
(330 mm)
30.0”
(762 mm)
13.0”
(330 mm)
13.0”
(330 mm)
F
igur
e 1: Oven Dimensions - Side
Figure 2: Oven Dimensions - Top
F
igure 3: Oven Dimensions - Front (Single)
Figure 4: Oven Dimensions - Front (Double)
F
igure 5: Oven Dimensions - Front (Triple)

TurboChef 2020 Specifications

General

Brand	TurboChef
Model	2020
Category	Oven
Language	English
