RFID channels — overview of commands
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 140
Example: Direct command in UHF applications (query read/write head version)
Request
Loop counter 0
Command code 0x0060
Read/write head address 0
Length UID/EPC 0
Start address 0
Length 2
Timeout 200
Write fragment No. 0
Read fragment No. 0
Write data 0x02 (CMD), 0x00 (application) – see debus protocol
Response
Loop counter 0
Response code 0x0060
Length 12
Error code 0
Tag in
detection range
0
Data (bytes) available 0
Tag counter 0
Write fragment No. 0
Read fragment No. 0
Read data 0x02, 0x00, 0x01, 0x02, 0x03, 0x04, 0x8B, 0x20, 0x00, 0x01,
0x00, 0x01
The read data can be interpreted via the debus protocol as follows:
MSG ERR SNR0 SNR1 SNR2 SNR3 GTYP VERS HW
0x02 0x00 0x01 0x02 0x03 0x04 0x8B
0x20
0x00
0x01
0x00
0x01
n Serial number: 0x01020304
n Device type: 0x208B
n Software version: v1.00
n Hardware version: v1.00
