Commissioning

Connecting the device to a Modbus master with CODESYS

Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com

07.00 | 2022/09 | 44

7.2.4 Modbus TCP slave — setting the IP address

 Double-click the Modbus TCP slave.

 In the General tab enter the IP address of the slave.

Fig.42: Modbus slave — entering the IP address (here: 192.268.1.61)
