turck TBEN-S2-2RFID-4DXP User Manual

Commissioning
Connecting the device to an EtherNet/IP scanner using RSLogix
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 67
7.3.5 EtherNet/IP — mapping
Description Assembly instance Value (words)
Input 103 191
Output 104 154
RFID channels — parameter data
Description Register Bit offset Bit length
Channel 0 Channel 1
Operating mode 0x000A 0x0041 0 8
Select tag type 0x000B 0x0042 0 8
bypass time 0x000C 0x0043 0 16
HF: Multitag 0x000D 0x0044 0 1
HF: Heartbeat read/write head 0x000E 0x0045 0 1
Cable termination active 0x000F 0x0046 0 1
HF: Automatic tuning of read/write
head
0x0011 0x0047 0 1
Deactivate diagnostic HF read/write
head tuning
0x0012 0x0048 0 1
Diagnostic input filter 0x0013 0x0049 0 1
Command repetitions in the event of
an error
0x0014 0x004A 0 8
HF: Command in Continuous Mode 0x0015 0x004B 0 8
HF: Length in Continuous Mode 0x0016 0x004C 0 16
HF: Address in Continuous Mode 0x0018 0x004E 0 32
Length of read data 0x003C 0x0072 0 16
Length of write data 0x003E 0x0074 0 16
HF bus mode: Activate read/write
head 1
0x001C 0x0052 0 1
HF bus mode: Activate read/write
head 2
0x001D 0x0053 0 1
HF bus mode: Activate read/write
head 3
0x001E 0x0054 0 1
… … … … 1
HF bus mode: Activate read/write
head 32
0x003B 0x0071 0 1
RFID channels — process input data
Description Word offset Bit offset Bit length
Channel 0 Channel 1
Response code 0x0001 0x004D 0 14
Error 0x0001 0x004D 14 1
Busy 0x0001 0x004D 15 1
Tag in detection range 0x0003 0x004F 0 1
HF read/write head switched on 0x0003 0x004F 8 1
