Operation
Using extended diagnostics — RFID channels
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 256
Status Description Values
Tag Error code of HF tag 1: The command is not implemented in this device
2: Command not detected, e.g. incorrect input format
3: Command option not supported
15: Undefined error
16: Addressed memory area not available
17: Addressed memory area locked
18: Addressed memory area locked and not writable
19: Write operation not successful
20: Addressed memory area could not be locked
160…223: User-specific error code
Air Error code of
HF air interface
1: CRC error
2: Timeout
4: HF tag error
8: HF tag outside of the detection range, before all commands could be
executed
16: Tag does not have the expected UID.
XCVR Error code of
HF read/write head
1: HF read/write head faulty
2: Error in command execution
4: Transmission window, check syntax
8: Power supply of the HF read/write head too low
16: Command code unknown
Error Error code of
UHF reader
32: The command is not implemented in this device
33: Unspecified error
34: A valid password is expected before the command is accepted.
36: Read operation not possible (e.g. invalid tag)
37: Write operation not possible (e.g. tag can only be read)
38: Verify after write operation failed
39: Access to unknown address (e.g. memory area outside of range)
40: The data to be sent is not valid.
42: The command requires a long time for execution.
44: The requested object is not in the persistent memory.
45: The requested object is not in the volatile memory.
53: The command is temporarily not permissible.
54: The opcode is not valid for this type of configuration memory.
128: No tag in the field
129: The EPC of the command does not match the EPC in the detection
range.
130: Incorrect tag type specified in the command
131: Write command to a block failed
General status General status of
UHF reader
The displayed values are based on the following bit structure:
Bit 1: Tag present
Bit 5: Test mode active
Bit 6: Read/write head configuration damaged, default settings are used.
Bit 7: Read/write head was reset (after reset).
RF status Status of the RF
module UHF reader
The displayed values are based on the following bit structure:
Bit 0: PLL not locked
Bit 1: Reverse power too high
Bit 2: Antenna resistance too high or too low
Bit 3: No free channel present
Bit 4: Limit value for radiated power exceeded
