TRANSPORT AND OPERATING POSITION
CONTROLS
Thetransport lock isused to keep the Power Rakein
the raised position when transporting the machine.
NOTE: When transporting the machine, the Power
Rake must be locked in the transport position or the
Power Rake or rotor may be damaged.
16
Transport Position
To position the Power Rake in the transport position:
1. Push down on the handlebars to raise the Power
Rake lock bar, A, until it is captured by the
Transport Lock, B.
2. Slowly reduce pressure on the handlebars. The
transport lock holds the Power Rake in the
transport position.
A
B
17
Operating Position
To position the PowerRake in the operating position:
1. Place light pressure on the Transport Lock
Control Lever, A. as shown.
A
18
