Turf Teq Sidewinder - Transmission Drive Belt Replacement Procedure

63
TRANSMISSION DRIVE BELT
REPLACEMENT PROCEDURE
Belt Removal
1. Remove the spark plug wire, A, from the spark
plug, B.
A
B
113
2. Remove thePowerRakemaindrive belt, A,from
the engine pulley as described in the “Remove
Main Drive Belt” section.
A
114
3. Remove transmission shield, A, after removing
two bolts, B.
A
B
B
115
