OPERATING THE POWER RAKE
STARTING THE POWER RAKE
1. Raise the Power Rake to the transport position
by pushing down on the handlebars until the
transport lock, A, engages lock bar, B, and holds
the attachment in the transport position as
described in the “Controls” section.
2. Adjust the depth adjustment cam to the desired
working depth as described in the “Controls”
section.
B
A
59
3. Start the engine and place the throttle to the run
position as described in the “STARTING THE
ENGINE” section.
60
4. Depress the POWER RAKE DRIVE CONTROL
ANDBRAKELEVER,A,asshown.Thisreleases
the attachment drive brake and engages the
drive
.
WARNING: Rotation of the rotor may cause
tractor to move backwards, under certain soil
conditions,iftractorisnotmovingforwardunder
power, or Tow Valve is in ON position.
CAUTION: Operating at excessive speeds can
causeexcessive wear ordamage to the machine.
NOTE: Engage attachment before lowering onto the
ground.
A
61
