46
LUBRICATION
Lubricate the following grease points every 10 hours
or on an annual basis whichever comes first.
Use a SAE all weather, high temperature, multipur-
pose grease.
Add grease to the fittings until there is a slight in-
crease in effort needed to operate the grease gun
handle.
CAUTION: Worn grease fittings that will not hold
thegun,andfittingswithastuckcheckball,must
be replaced.
Items not equipped with grease fittings (linkages,
cables, pins, levers, etc.) should be lubricated with
SAE 30 oil before the start of each operating day, or
more frequently as conditions require.
Dolly wheels -- Apply grease to zerk, A, on each
wheel.
A
69
Attaching pivot located at the pivot located under the
frame below the engine. Apply grease to zerk, A.
A
70
