74
13. Placethemaindrivebelttensionlever,A,forward
to the engaged position.
A
144
14. Operate the Power Rake for proper operation
and correct any problem before placing the
machine back in service.
ROTOR TEETH INSPECTION AND REPLACEMENT
The rotor teeth contact the ground and perform the
tilling operation.
Rotor tooth length is crucial to efficient operation.
NOTE: Teeth should be checked daily for wear and
replaced when teeth are 1/2 inch minimum.
WARNING: To prevent injury perform the
following before starting work:
1. Position the Power Rake on a flat level hard
surface.
2. Lower the power Rake to the ground.
3. If the power Rake must be raised to perform
work you must place blocking under the
Power Rake frame before doing any work.
4. Allow the machine to cool to ambient
temperature before working on the Power
Rake.
5. Remove the spark plug wire from the spark
plug.
