73
8. Move the gearbox toward the tractor to tighten
the chain and reduce slack.
9. Snug two attaching bolts thenrecheck slack.For
1/4to3/4inchslackatA.
10. Repeat steps 8 and 9 until the proper slack is
obtained.
A
141
11. Tighten the five attaching bolts loosened
previously. The four gearbox mounting bolts, A,
and the mounting bolt that attaches the inner
gearbox support bracket to the frame.
A
142
12. Install the shield, A, and tighten three bolts, B.
A
B
B
B
143
