61
7. Adjust dimension at A, from the frame to
centerline of the transmission shaft to 3-5/8 to
3-3/4 inches.
A
108
8. Tighten the two axle to frame attaching bolts, A,
for the left axle. Tighten the two axle to frame
bolts on the right axle.
A
A
109
9. Tighten attaching bolt, A.
A
110
