Turf Teq Sidewinder - Rotor Drive Chain Adjustment

68
16. Install cable yoke, B, on the stud. Put two drops
ofredLocktite#277onthethreadsofthejamnut,
A, then tighten on the stud until there is 1/64 inch
clearance between the jam nut and the yoke.
A
B
128
17. Reinstall the clutch brake torque strap. Put two
drops of red Locktite #277 on the threads of the
jam nut, A, then tighten securely.
A
129
18. Check that the transmission drive belt, A, is
trackingcorrectlyandnotcontactinganyobjects.
A
130
