Gauge Dive ALT information includes (Fig. 90) -
> Temperature with degrees icon and graphic F (or C)
> Time of Day (hr:min) with clock and AM (or PM) icons
> Max Depth with FT (or M) and MAX icons
• The display will revert to the MAIN screen after 5 seconds
or if the A button is pressed.
• Press the L button to activate the Backlight.
As in NORM Dive Mode, if you descend deeper than the MOD
(Max Operating Depth) of 330 FT (99.9 M), a cautionary mode
referred to as Delayed Violation 3 will be activated.
DV3 Main information includes (Fig. 91) -
> Graphic GAU
> EDT (hr:min) with wave/clock icon
> Up Arrow icon (flashing)
> Current Depth as 3 dashes ( - - - ) flashing with FT (or M)
icon
> ASC - if ascending
• Press and release the S button momentarily (< 2 sec) to
acknowledge/silence Alarms.
• Press and release the A button momentarily (< 2 sec) to
access the ALT screen.
• Press the L button to activate the Backlight.
Fig. 90 - GAUG DIVE ALT
Fig. 91 - GAUG DV3 MAIN
