13
Technical Information
Motor Specication
Power - DC 12, 24, 12/24 12 - 24 VDC
HP (horsepower) rating 1/3 HP
Power cable length 20’
Power cable gauge 10 AWG
Power cable DC battery connectors No
Amps (MAX) 30 - 15 Amp
RPM Variable 400 - 3500
Duty cycle Continuos
Thermal protection Electronically Protected
Circuit protection fuse Yes (35 Amp Fuse)
Certication UL/cUL Motor/CE
Pump
Design Positive Displacement Rotary Vane
Flow rate (with supplied hose / nozzle) Up to 25 GPM / 95 LPM
Flow rate open ow - no hose or nozzle Up to 28 GPM / 106 LPM
Max discharge pressure 21 PSI
Dry vac (in Hg) 11 in vacuum
Head- Max (ft) 48’
Anti-siphon valve None
Inlet - size / thread 1-1/4” NPT / BSPP
Outlet – size / thread 1” NPT / BSPP
Mount 2” Bung NPT or BSPT
Materials of construction -pump housing Cast Iron
Materials of construction- wetted material BUNA-N + Fluorocarbon
Rotor materials of construction Powdered Iron
Rotor vane material of construction Acetal
Compatible uids Diesel, Gasoline, BioDiesel up to B20, E15, Kerosene, Mineral Spirits,
Methanol (up to 15%)
Strainer mesh size 20 x 20
Warranty (yr) 2 Year
Maximum sound level 75.3 dB
